Beschrijving
Technische data
Speaker TypeActive Cardiod-Subwoofer
Akoestische gegevens
Frequency Response [+/- 3dB]35 – 120 Hz
Max SPL140 dB
DirectivityCardiod
LF18+15 ”
Voice Coil LF4 ”
Amplifier
Amp TechnologyDigipro® G2
Amp ClassClass D
Power Supply2.5 kW SMPS
LF Amp2500 W RMS
CoolingConvection
Processor
ControllerDSP 56 bit
AD/DA Converter24bit/ 96 kHz
System PresetsX-Over,Delay
Phase0, 180 °
LimiterRMS, Peak, Thermal
Delay Option0-4.5 ms internal
Crossover Frequency LF-MF75-120Hz | steps of 5Hz
LF-Xover out slope24 dB/Octave
Mechanica
HousingMultiplex plywood
Housing DesignRectangular
Handles3x Per Side
AccessoryDolly, Dust Cover, Rain Cover
Pole MountM20
Rigging Pointsintegrated for SRK10 fly kit
2xPick Points on top to fix
DRK10/20 rigging frames
Width515 mm (20.6 in)
Height640 mm (25.6 in)
Depth1000 mm (40 in)
Weight65 kg (143.3 lbs)
